MRCOOL Advantage Series 4th Gen : A-12-HP-115C

Description

This new 4th generation MRCOOL Advantage Series now features an improved SEER of 20. Once installed by an HVAC technician, this efficient system immediately provides high performance comfort. This air handler and condenser combination provides superior value, quality, and efficiency, with a quiet operation. In order to be more eco-friendly, the condenser uses chlorine-free R-410A refrigerant. This is an excellent choice for those who want both comfort and technology, thanks to the WiFi control module. It allows for easier setup, improved functionality, and allows you to use your Amazon Alexa or Google Assistant to control the system.

• Installation kit included
• Gold Fin® condenser: corrosion resistant – live on the coast? Don’t worry, our condenser is built to resist long term corrosion
• The new 4th generation Advantage systems include our SmartHVAC WiFi Control Module with improved setup and enhanced functionality for Apple and Android smart devices. Works with Amazon Alexa. Works with Google Assistant.
• Installation by a licensed professional required where applicable
• 1-Year Compressor, 2-Year Parts and 1-Year Remote Warranty when registered and when installed by a licensed professional
• R-410A environmentally friendly refrigerant
• Sleep mode, louver position memory, and auto restart functions
• Convenient for installation and maintenance, compact design of outdoor unit, totally enclosed, permanently lubricated condenser fan motor
• ,  ,  ,

UPC: 840255521826
country_of_origin:

WARRANTIES:

registered_warranty:1-Year Compressor, 2-Year Parts and 1-Year Remote
base_warranty:None
registered_parts_warranty: 2-year
base_parts_warranty: None
registered_compressor_warranty: 1-year
base_compressor_warranty: None
registered_heat_exchanger_warranty:
base_heat_exchanger_warranty:
registered_remote_warranty: 1-year
base_remote_warranty: None
registered_labor_warranty: None
base_labor_warranty:None

TECHNICAL SPECIFICATIONS: (blank value means does not apply or not available)

Accessory_Type: NA
cased: NA
configuration:
works_with:
seer: 20
seer2: 20.8
max_seer:
eer: 10.3
eer2: 10.3
eer_part_load:
cop_47:
cop_47_part_load:
hspf: hspf4/hspf5: 10.5/8.4
hspf2: hspf2-4/hspf2-5: 8.7/6.6
afue:
cfm:
tonnage:
cooling_capacity: 12000
heating_capacity: 12000
fuel_type: Electric
btu_input:
btu_output:
voltage: 115V   phase: 1
cycle: 60Hz
stage:
max_fuse_breaker: 25 A
min_circuit_ampacity: 18.5 A
mount_type:
color: White
color_family:
rated_load:
full_load:
max_coverage_area: 500 sqft
zone_capacity: 1
refrigerant_type: R-410A
refrigerant_volume: 28.57oz
decibel_rating: 30.5 dBA
decibel_rating_low: 26 dBA
decibel_rating_high: 41.5 dBA
air_flow_direction:
number_of_speeds: 3
oscillation:
number_of_burners:
inverter:
min_ambient_cool:
min_ambient_heat: 5 Degrees F
drain_connection_size:
gas_connection_size:
lineset_included:
line_set_length:
max_lineset_length:
lineset_fitting_type:
liquid_line_fitting:
liquid_line_size:
suction_line_fitting:
suction_line_size: 1/2 in
control_type:
compressor_motor_type:
condenser_fan_motor_type:
condenser_fan_motor_hp:

condenser_fan_motor_rpm:
blower_motor_type:
blower_motor_hp:
blower_motor_speeds:
blower_motor_rpm:
filter_type: Washable
filter_size:
heat_exchanger_type:
ignition_type:
vent_connector:
metering_device:
auxiliary_heater_included:
auxiliary_heater_available:
auxiliary_heater_sizes:
lp_kit_included:
lp_kit_available:
low_voltage_compensation: No
overload_protection: Yes
adjustable_thermostat: Yes
fan_only_option: Yes
quiet_mode: Yes
sleep_mode: No
auto_cool: Yes
wifi_compatibility: Yes
app_compatibility: Yes
works_with_ios: Yes
works_with_android: Yes
remote_control_included: Yes
ul_reconized:
ul_listed: Yes

csa_listed: Yes
csa_certified:
etl_listed: Yes
etl_certified:
iso_certified;
leed_certified:
ashrae_compliant:
energy_star_compliant: No
energy_star_certified: No
ahri_certified: Yes
has_batteries: Yes
contains_electronics: Yes
contains_chemicals: Yes
contains_aerosol: Yes
contains_compressed_gas: Yes
proposition_65_warning: Yes
restricted_states:
net_depth:
net_height:
net_width:
net_weight:
gross_depth:
gross_height:
gross_width:
gross_weight:
condenser_depth: 11.93 in
condenser_height: 21.85 in
condenser_width: 30.12 in
condenser_weight: 62.17 lbs
air_handler_depth: 7.44 in
air_handler_height: 11.69 in
air_handler_width: 31.57 in
air_handler_weight: 19.84 lbs
freight_class:

COPY AND PASTE FOLLOWING MANUAL URLS:

brochure: https://mrcool.com/wp-content/dox_repo/mc-adv-4-br-en-01.pdf
install_manual: https://mrcool.com/wp-content/dox_repo/mc-adv-4-im-en-01.pdf
specs:
owner_manual:
remote_manual:
technical_manual:
service_manual: https://www.mrcool.com/wp-content/dox_repo/mc-adv-4-ah-cond-sm-en-01.pdf
warranty_doc:
accessory_manual_1:
accessory_manual_2:
accessory_manual_3:
ahri_certs: https://mrcool.com/wp-content/dox_repo/AHRI/mc-adv-4-12-115-Certs.pdf
energy_guide_certs: https://mrcool.com/wp-content/dox_repo/EnergyGuide/mc-adv-4-12-115-EG.PDF
other_certs:
misc_doc4:
